FeCrAl
The product forms include wire, strip, plate, bar, wire mesh, powder, pipe, etc. Click to view.
Share to
Category
Tag list
- 详细描述
-
Product application
Iron-chromium-aluminum(FeCrAl) alloy is an important electric heating alloy, containing high chromium and aluminum elements, which makes it have high resistivity and high temperature resistance. It has excellent oxidation resistance at high temperature, and the operating temperature can reach 1400℃. FeCrAl Alloy is relatively low in price and is widely used in heating elements of large industrial furnaces such as heat treatment furnaces, kilns, sintering furnaces, and can also be used in household appliances, automobile exhaust purifiers and other fields.
The main FeCrAl alloy grades produced by Chengyuan Alloy include 1Cr13Al4, 0Cr23Al5, 0Cr27Al7Mo2 etc. The main production forms include wire, flat wire, strip, plate, rod, wire mesh, etc.
Chemical composition %
Grade Ni Cr Fe Al Si C P S Mn Ti Nb Mo Ca Ce Ba 1Cr13Al4 ≤0.6 12-15 Bal. 4.0-6.0 ≤1 ≤0.12 ≤0.025 ≤0.025 ≤0.7 0Cr23Al5 ≤0.6 20.5-23.5 Bal. 4.2-5.3 ≤0.6 ≤0.06 ≤0.025 ≤0.025 ≤0.7 0Cr21Al6 ≤0.6 19-22 Bal. 5.0-7.0 ≤1 ≤0.06 ≤0.025 ≤0.025 ≤0.7 0Cr25Al5 ≤0.6 23-26 Bal. 4.5-6.5 ≤0.6 ≤0.06 ≤0.025 ≤0.025 ≤0.7 0Cr21Al6Nb ≤0.6 21-23 Bal. 5.0-7.0 ≤0.6 ≤0.05 ≤0.025 ≤0.025 ≤0.7 0.5 0Cr27Al7Mo2 ≤0.6 26.5-27.8 Bal. 5.0-7.0 ≤0.4 ≤0.05 ≤0.025 ≤0.025 ≤0.2 1.8-2.2 Mechanical properties
Grade Tensile strength,Mpa (kgf/mm2 ) Elongation%, not less than Resistivity,μΩ·m All wires with diameters > 3.0mm All wires with diameters of 0.10mm~3.0mm and FeCrAl strips with thickness >0.2mm 1Cr13Al4 ≥580 15 12 1.25±0.08 0Cr23Al5 ≥600 15 12 1.35±0.06 0Cr21Al6 ≥630 12 12 1.42±0.07 0Cr25Al5 ≥600 15 12 1.42±0.07 0Cr21Al6Nb ≥650 12 10 1.45±0.07 0Cr27Al7Mo2 ≥680 10 10 1.53±0.07 Supply form and specification
From Specification Wire Ø 0.1-10 mm Flat wire Width=1~5 mm, Thick=0.08~2 mm Strip Width=8~250mm, Thick=0.1~3.0mm Foil Width=6~120mm, Thick=0.01~0.1mm Bar Diameter=5~100mm, Length=50~5000mm
Contact us so we can better understand you
Every customer has their own needs, their own standards to adhere to and their own projects with unique specifications. Cheng Yuan is a partner in finding the right solution first time.
Ask a question, request information or enquire whichever way best suits you. Live chat with an expert, use any of our forms or contact us by phone or email.
